| Code |
Heigh
mm |
Insert
mm |
Operating voltage
V |
| CT/P 30 |
30 |
M6 |
750 |
| |
|
M8 |
|
| |
|
M10 |
|
| CT/P 35 |
35 |
M8 |
750 |
| |
|
M10 |
|
| CT/P 40 |
40 |
M8 |
1000 |
| |
|
M10 |
|
| |
|
M12 |
|
| CT/P 45 |
45 |
M8 |
1000 |
| |
|
M10 |
|
| |
|
M12 |
|
| CT/P 50 |
50 |
M8 |
1500 |
| |
|
M10 |
|
| |
|
M12 |
|
| CT/P 55 |
55 |
M8 |
1500 |
| |
|
M10 |
|
| CT/P 60 |
60 |
M8 |
1500 |
| |
|
M10 |
|
| |
|
M12 |
|
| CT/P 65 |
65 |
M8 |
1500 |
| |
|
M10 |
|
| CT/P 70 |
70 |
M8 |
1500 |
| |
|
M10 |
|
Material: Polyglass polyester
Operating temperature: -40º C ~ +130º C
Fire reaction / Class: UL94 – VO; HL2; EN 45545-2
Breaking charges: tolerance +/- 10%
| Type |
CT/P30 |
CT/P40 |
CT/P50 |
CT/P60 |
AC sufrace flashover voltage
kV |
8 |
10 |
10 |
10 |
AC internal flashover voltage
kV |
20 |
25 |
35 |
35 |
Tensile strength
DN |
1000 |
1000 |
1000 |
1000 |
Flexural strength
DN |
750 |
700 |
500 |
370 |
Compressive strenght
DN |
8000 |
8000 |
8000 |
8000 |
Torsional strenght
DN x mm |
3-6 |
3-6 |
3-6 |
3-6 |
1DN~1Kg
